Aircraft / Cessna / 182 / 182N
Cessna Certified · Fixed-wing · United States
182N
Seats 4 4
Power 230 hp 172 kW
Cruise 145 kt 269 km/h
US register 332 aircraft 332 aircraft
Photo: HawkeyeUK · CC BY-SA 2.0 Photo: CaptainN1435S · CC BY 4.0 Photo: kitmasterbloke · CC BY 2.0 Photo: Asylumkid · CC BY-SA 2.0
About the 182N
The Textron Aviation 182N is an American type-certificated, single-engine fixed-wing aircraft designed as a four-seat light airplane, with the provision to add a pair of child seats in the baggage area. Produced by Cessna, it utilizes an air-cooled flat-six powerplant paired with a constant-speed propeller and features an all-metal airframe complemented by fiberglass or thermoplastic cowlings and wingtips.
First appearing in the nineteen-fifties as a tricycle gear iteration of an earlier model, the type evolved through numerous variants encompassing fuselage widenings, modified tails, and gross weight increases. Production experienced pauses and restarts over the decades, and international manufacturing also took place in countries such as France and Argentina. Alongside standard aviation gasoline powerplants, experimental diesel iterations and specialized utility configurations have been explored.
Engines fitted 327 aircraft
Engine Power Share of fleet Aircraft
Continental O-470
230 hp
325
Continental IO-520
300 hp
2
The 182N is a variant of the Cessna 182 . Other variants: 182A , 182B , 182C , 182D , 182E , 182F , 182G , 182H , 182J , 182K , 182L , 182M , 182P , 182Q , 182R , 182RG , 182S , 182T .
Specifications Cessna 182T · Lycoming IO-540-AB1A5
US Metric
Dimensions
Length 29 ft 0 in 8.84 m 8.84 m 29 ft 0 in
Wingspan 36 ft 0 in 10.97 m 10.97 m 36 ft 0 in
Wing area 174 sq ft 16.2 m² 16.2 m² 174 sq ft
Weights
Empty weight 1,970 lb 894 kg 894 kg 1,970 lb
Max take-off weight 3,100 lb 1,406 kg 1,406 kg 3,100 lb
Performance
Cruise speed 145 kt 269 km/h 269 km/h 145 kt
Max speed 150 kt 278 km/h 278 km/h 150 kt
Never-exceed speed (Vne) 175 kt 324 km/h 324 km/h 175 kt
Stall speed 49 kt 91 km/h 91 km/h 49 kt
Range 930 nm 1,722 km 1,722 km 930 nm
Service ceiling 18,100 ft 5,517 m 5,517 m 18,100 ft
Rate of climb 920 ft/min 4.7 m/s 4.7 m/s 920 ft/min
Powerplant
Engine Lycoming IO-540-AB1A5
Engine power 230 hp 172 kW 172 kW 230 hp
ICAO type designator C182
Type certificate US 3A13
On the US register 332
Registered in Brazil, United Kingdom, New Zealand, Australia, United States, Canada
1971 · 6,750 h USD
Low $128,000
Typical $145,000
High $163,000
By year built · United States · USD
Built Hours Low Typical High
1970 6,750 $144,000 $163,000 $183,000 1971 6,750 $128,000 $145,000 $163,000
By year built · United Kingdom · GBP
Built Hours Low Typical High
1970 4,770 £98,000 £125,000 £156,000 1971 4,770 £87,000 £111,000 £139,000
By year built · Euro countries · EUR
Built Hours Low Typical High
1970 4,770 €117,000 €149,000 €187,000 1971 4,770 €104,000 €132,000 €166,000
182N running costs $281 an hour
A year
Low Typical High
Fuel $7,927 $10,168 $11,827 Oil $184 $230 $299 Engine overhaul reserve $3,333 $3,958 $5,192 Propeller overhaul reserve $917 $1,083 $1,250 Annual inspection and maintenance $3,000 $4,000 $5,000 Hangar $3,000 $6,300 $9,600 Insurance $1,866 $2,364 $2,862
Total $20,227 $28,103 $36,030
Per hour $202 $281 $360
Engine
Model Continental O-470
Power 230 hp
Overhaul 1,500 h / 12 yr
Fuel burn 10.5 – 13.2 gal/h
Fuel price $8.20 /US gal
