How much does a used Piper PA-24-180 cost?

Name: Piper PA-24-180
Brand: Piper

PLANEFILE

PiperCertified · Fixed-wing · United States

PA-24-180

Seats: 4 4
Power: 260 hp194 kW
Cruise: 161 kt298 km/h
US register: 196 aircraft196 aircraft

About the PA-24-180

Piper PA-24-180 is a type-certificated, fixed-wing aircraft built in the United States. Functioning as a retractable-gear piston airplane, it suits private aviators, flight schools, and cross-country travel. The layout features a single piston engine and cabin seating for four occupants.

The aircraft design first took to the air in the mid-twentieth century, featuring a low-mounted laminar-flow wing, retractable landing gear, a swept tail, and an all-moving stabilator. Over its production run, various versions were introduced with different powerplants, increased fuel capacities, and auxiliary tanks. It remained in production for over a decade, resulting in thousands of airframes built.

Engines fitted

196 aircraft

Engine	Power	Aircraft
Lycoming O-360	180 hp	191
Lycoming O-540	250 hp	3
Aerosport O-360-A1A	180 hp	1
Lycoming AEIO-360	180 hp	1

The PA-24-180 is a variant of the Piper PA-24 Comanche. Other variants: PA-24-250, PA-24-260, PA-24-400.

Specifications

PA-24-260C · Lycoming IO-540

Dimensions

Length: 25 ft 0 in 7.62 m7.62 m 25 ft 0 in
Wingspan: 36 ft 0 in 10.97 m10.97 m 36 ft 0 in
Wing area: 178 sq ft 16.5 m²16.5 m² 178 sq ft

Weights

Empty weight: 1,773 lb 804 kg804 kg 1,773 lb
Max take-off weight: 3,200 lb 1,451 kg1,451 kg 3,200 lb

Performance

Cruise speed: 161 kt 298 km/h298 km/h 161 kt
Max speed: 169 kt 314 km/h314 km/h 169 kt
Never-exceed speed (Vne): 197 kt 365 km/h365 km/h 197 kt
Stall speed: N/A
Range: 1,064 nm 1,971 km1,971 km 1,064 nm
Service ceiling: 19,500 ft 5,944 m5,944 m 19,500 ft
Rate of climb: 1,320 ft/min 6.7 m/s6.7 m/s 1,320 ft/min

Powerplant

Engine: Lycoming IO-540
Engine power: 260 hp 194 kW194 kW 260 hp

Capacity

Seats: 4

Manufacturer: Piper
Country: United States
On the US register: 196
Registered in: United Kingdom, United States, Canada
Official website: piper.com

Improve this page

Add your photos Suggest a correction

PA-24-180 prices

Asking prices of those for sale now, US dollars

Asking prices for the 4 Piper PA-24-180 aircraft for sale with a price run from $63,500 to $75,000, with a median of $67,500. Half ask between $65,000 and $70,000.

PA-24-180 running costs

$218 an hour

Hours a year Aircraft value (USD)

A year
	Low	Typical	High
Fuel	$6,191	$7,954	$9,229
Oil	$144	$180	$234
Engine overhaul reserve	$2,167	$2,667	$4,833
Annual inspection and maintenance	$2,500	$3,500	$4,500
Hangar	$3,000	$6,300	$9,600
Insurance	$908	$1,192	$1,478

Total	$14,910	$21,793	$29,874
Per hour	$149	$218	$299
