How much does a used Aviat Aircraft Eagle cost?

Name: Aviat Aircraft Eagle
Brand: Aviat Aircraft

PLANEFILE

Aviat AircraftExperimental & kit · Fixed-wing · United States

Eagle

Seats: 2 2
Power: 200 hp149 kW
Cruise: 143 kt266 km/h
US register: 8 aircraft8 aircraft

About the Eagle

The Christen Industries Eagle is a homebuilt, fixed-wing, single-engine aerobatic biplane designed with side-by-side seating for two occupants. It suits enthusiasts and competitors seeking high-performance aerobatic capabilities coupled with fine craftsmanship.

Created by Frank Christensen, the aircraft is widely known through the legendary exhibition flying of the Eagles Aerobatic Flight Team, whose show planes are preserved in museum collections. Rights to the kit production have transitioned across manufacturers over the decades while maintaining a dedicated community of builders and pilots.

Engines fitted

8 aircraft

Engine	Power	Aircraft
Lycoming AEIO-360	180 hp	4
Lycoming IO-540	260 hp	2
Lycoming O-360	180 hp	1
Lycoming IO-360	200 hp	1

This page covers the Aviat Aircraft Eagle: the same aircraft under other designations.

Specifications

Textron Lycoming AEIO-360-A1D

Dimensions

Length: 17 ft 0 in 5.18 m5.18 m 17 ft 0 in
Wingspan: 19 ft 0 in 5.79 m5.79 m 19 ft 0 in
Wing area: 125 sq ft 11.6 m²11.6 m² 125 sq ft

Weights

Empty weight: 1,025 lb 465 kg465 kg 1,025 lb
Max take-off weight: 1,578 lb 716 kg716 kg 1,578 lb

Performance

Cruise speed: 143 kt 266 km/h266 km/h 143 kt
Max speed: 160 kt 296 km/h296 km/h 160 kt
Never-exceed speed (Vne): 182 kt 338 km/h338 km/h 182 kt
Stall speed: 50 kt 93 km/h93 km/h 50 kt
Range: 380 nm 703 km703 km 380 nm
Service ceiling: 17,000 ft 5,182 m5,182 m 17,000 ft
Rate of climb: 2,100 ft/min 10.7 m/s10.7 m/s 2,100 ft/min

Powerplant

Engine: Textron Lycoming AEIO-360-A1D
Engine power: 200 hp 149 kW149 kW 200 hp

Capacity

Seats: 2

ICAO type designator: ZZZZ
Manufacturer: Aviat Aircraft
Country: United States
On the US register: 8
Registered in: Brazil, United States

Improve this page

Add your photos Suggest a correction

Eagle prices

Asking prices of those for sale now, US dollars

Asking prices for the 2 Aviat Aircraft Eagle aircraft for sale with a price run from $57,588 to $140,000, with a median of $98,800.

Eagle running costs

$221 an hour

Hours a year Aircraft value (USD)

A year
	Low	Typical	High
Fuel	$6,191	$7,954	$9,229
Oil	$144	$180	$234
Engine overhaul reserve	$2,167	$2,667	$4,833
Annual inspection and maintenance	$2,500	$3,500	$4,500
Hangar	$3,000	$6,300	$9,600
Insurance	$1,189	$1,537	$1,884

Total	$15,191	$22,138	$30,280
Per hour	$152	$221	$303
