Eagle II

Seats: 2 2
Power: 200 hp149 kW
Cruise: 143 kt266 km/h
US register: 11 aircraft11 aircraft

About the Eagle II

The Aviat Eagle II is an American aerobatic sporting biplane built for amateur homebuilding. It is well suited for pilots seeking precision aerobatic performance and features a tandem two-seat configuration with a single piston engine.

Originally created by a designer from Utah to rival another popular aerobatic model, the aircraft is supplied in kit form. It utilizes a welded steel tube fuselage paired with wooden wings, all fabric-covered, alongside a fixed tailwheel undercarriage. A famous formation flight team adopted the type for their airshow performances, eventually leading to the display of their retired aircraft in a museum lobby.

Engines fitted

10 aircraft

Engine	Power	Share of fleet	Aircraft
Lycoming AEIO-360	180 hp		10

This page covers the Aviat Aircraft EAGLE II: the same aircraft under other designations.

Specifications

Textron Lycoming AEIO-360-A1D

Dimensions

Length: 17 ft 0 in 5.18 m5.18 m 17 ft 0 in
Wingspan: 19 ft 0 in 5.79 m5.79 m 19 ft 0 in
Wing area: 125 sq ft 11.6 m²11.6 m² 125 sq ft

Weights

Empty weight: 1,025 lb 465 kg465 kg 1,025 lb
Max take-off weight: 1,578 lb 716 kg716 kg 1,578 lb

Performance

Cruise speed: 143 kt 266 km/h266 km/h 143 kt
Max speed: 160 kt 296 km/h296 km/h 160 kt
Never-exceed speed (Vne): 182 kt 338 km/h338 km/h 182 kt
Stall speed: 50 kt 93 km/h93 km/h 50 kt
Range: 380 nm 703 km703 km 380 nm
Service ceiling: 17,000 ft 5,182 m5,182 m 17,000 ft
Rate of climb: 2,100 ft/min 10.7 m/s10.7 m/s 2,100 ft/min

Powerplant

Engine: Textron Lycoming AEIO-360-A1D
Engine power: 200 hp 149 kW149 kW 200 hp

Capacity

Seats: 2

Manufacturer: Aviat Aircraft
Country: United States
On the US register: 11
Registered in: United States

Improve this page

Add your photos Suggest a correction

Eagle II running costs

$206 an hour

Hours a year Aircraft value (USD)

A year
	Low	Typical	High
Fuel	$6,191	$7,954	$9,229
Oil	$144	$180	$234
Engine overhaul reserve	$2,167	$2,667	$4,833
Annual inspection and maintenance	$2,500	$3,500	$4,500
Hangar	$3,000	$6,300	$9,600

Total	$14,002	$20,601	$28,396
Per hour	$140	$206	$284
