Mfi-9 Junior

Seats: 2 2
Power: 100 hp75 kW
Cruise: 116 kt215 km/h

About the Mfi-9 Junior

The Bölkow MFI-9 Junior is a light fixed-wing aircraft produced in Sweden and under licence in West Germany, featuring a shoulder-wing layout and a tricycle undercarriage. It provides an enclosed cockpit with seating for two occupants and suits private owners and trainers.

The aircraft was originally designed by an engineer working in his spare time while residing in the United States, before he returned to Sweden to join Malmö Flygindustri. Subsequent variants included dedicated trainer versions, and hundreds of units were constructed under licence by a German firm. Numerous examples continue to survive in private hands across Scandinavia, Europe, and other regions.

Specifications

MFI-9B · Rolls-Royce/Continental O-200-A

Dimensions

Length: 19 ft 2 in 5.85 m5.85 m 19 ft 2 in
Wingspan: 24 ft 5 in 7.43 m7.43 m 24 ft 5 in
Wing area: 94 sq ft 8.7 m²8.7 m² 94 sq ft

Weights

Empty weight: 750 lb 340 kg340 kg 750 lb
Max take-off weight: 1,268 lb 575 kg575 kg 1,268 lb

Performance

Cruise speed: 116 kt 215 km/h215 km/h 116 kt
Max speed: 127 kt 236 km/h236 km/h 127 kt
Never-exceed speed (Vne): 165 kt 305 km/h305 km/h 165 kt
Stall speed: 43 kt 80 km/h80 km/h 43 kt
Range: 432 nm 800 km800 km 432 nm
Service ceiling: 14,750 ft 4,500 m4,500 m 14,750 ft
Rate of climb: 850 ft/min 4.3 m/s4.3 m/s 850 ft/min

Powerplant

Engine: Rolls-Royce/Continental O-200-A
Engine power: 100 hp 75 kW75 kW 100 hp

Capacity

Seats: 2

Manufacturer: Bolkow
Country: Germany
Official website: airbus.com

Improve this page

Add your photos Suggest a correction

Mfi-9 Junior running costs

$177 an hour

Hours a year Aircraft value (USD)

A year
	Low	Typical	High
Fuel	$3,398	$4,428	$5,197
Oil	$80	$100	$130
Engine overhaul reserve	$2,167	$2,667	$4,833
Annual inspection and maintenance	$2,500	$3,500	$4,500
Hangar	$3,000	$6,300	$9,600
Insurance	$540	$744	$947

Total	$11,685	$17,739	$25,207
Per hour	$117	$177	$252
