How much does a used Mooney M-20M Tls cost?

Name: Mooney M-20M Tls
Brand: Mooney

PLANEFILE

MooneyOther aircraft · Fixed-wing · United States

M-20M Tls

Seats: 4 4
Power: 280 hp209 kW
Cruise: 175 kt324 km/h

About the M-20M Tls

The Mooney M-20M TLS is a single-engine, fixed-wing piston aircraft built for high-performance and long-range travel. It features a layout accommodating four occupants and is well suited for pilots who prioritize raw speed and climbing capability during cross-country flights.

Introduced following the expansion of the manufacturer's model line, the design emerged by mating a stretched fuselage with a large turbocharged engine. Initially known by a flight-test nickname, it represented a shift away from traditional company efficiency toward ultimate performance. Later variants received built-in oxygen and speed brakes as standard equipment, along with a name change to reflect its updated branding.

The M-20M Tls is a variant of the Mooney M-20M Bravo.

Specifications

figure for the M-20M Bravo · Continental TSIO-550-G

Dimensions

Length: 26 ft 0 in 7.92 m7.92 m 26 ft 0 in
Wingspan: 36 ft 0 in 10.97 m10.97 m 36 ft 0 in
Wing area: 175 sq ft 16.2 m²16.2 m² 175 sq ft

Weights

Empty weight: 2,380 lb 1,080 kg1,080 kg 2,380 lb
Max take-off weight: 3,368 lb 1,528 kg1,528 kg 3,368 lb
Fuel capacity: 89.0 US gal 337 L337 L 89.0 US gal

Performance

Cruise speed: 175 kt 324 km/h324 km/h 175 kt
Max speed: 242 kt 448 km/h448 km/h 242 kt
Stall speed: 53 kt 98 km/h98 km/h 53 kt
Range: 1,100 nm 2,037 km2,037 km 1,100 nm
Service ceiling: 25,000 ft 7,620 m7,620 m 25,000 ft

Powerplant

Engine: Continental TSIO-550-G
Engine power: 280 hp 209 kW209 kW 280 hp

Capacity

Seats: 4

ICAO type designator: M20T
Manufacturer: Mooney
Country: United States
Registered in: Germany
Official website: mooney.com

Improve this page

Add your photos Suggest a correction

M-20M Tls prices

Asking prices of those for sale now, US dollars

Asking prices for the 6 Mooney M-20M Tls aircraft for sale with a price run from $111,930 to $335,000, with a median of $223,000. Half ask between $179,000 and $270,000.

{# the label links to these aircraft for sale, built in that span. On the label and not the count: the bands count every aircraft on the market (on_market) while the grid shows only those with a photo (live), so the count is not a promise of how many cards appear. A band cached before year_min existed renders as plain text rather than a link to an unfiltered list. #}

By year built
Built	For sale	Median asking	Range	Median hours
1990–1994	3	$210,000	$179,000 – $235,500	2,800
1995–1999	4	$270,000	$111,930 – $335,000	2,400

M-20M Tls running costs

$323 an hour

Hours a year Aircraft value (USD)

A year
	Low	Typical	High
Fuel	$9,588	$12,300	$14,426
Oil	$224	$280	$364
Engine overhaul reserve	$4,583	$5,417	$8,842
Propeller overhaul reserve	$917	$1,083	$1,250
Annual inspection and maintenance	$3,000	$4,000	$5,000
Hangar	$3,000	$6,300	$9,600
Insurance	$2,307	$2,903	$3,499

Total	$23,619	$32,283	$42,981
Per hour	$236	$323	$430
