How much does a used Vans Aircraft RV-10 cost?

Name: Vans Aircraft RV-10
Brand: Vans Aircraft

Asking prices for the 30 Vans Aircraft RV-10 aircraft for sale with a price run from $3,511 to $643,025, with a median of $399,000. Half ask between $344,000 and $455,000.

PLANEFILE

Vans AircraftExperimental & kit · Fixed-wing · United States

RV-10

Seats: 5 5
Power: 260 hp194 kW
Cruise: 171 kt317 km/h
US register: 725 aircraft725 aircraft

About the RV-10

The Vans Aircraft RV-10 is a homebuilt, single-engine, low-wing touring airplane originating in the United States. Designed to accommodate four occupants, it provides a stable layout with a tricycle landing gear and gull-winged cabin doors instead of traditional canopies. It is intended for pilots seeking greater payload capacity and stable cross-country performance rather than aerobatic handling.

Developed as the first four-seat model in a popular series, the prototype flew in mid-2003, with thousands completed by builders worldwide. The construction relies on aluminum airframes combined with composite cabin structures, utilizing pre-drilled rivet holes to streamline the amateur building process. Builders can also install an optional ballistic parachute system in the baggage bay.

Engines fitted

527 aircraft

Engine	Power	Aircraft
Lycoming IO-540	260 hp	364
Lycoming YIO-540	260 hp	142
Aerosport IO-540-D4A5	260 hp	21

This page covers the Vans Aircraft RV 10A: the same aircraft under other designations.

Specifications

RV-10 · Lycoming O-540

Dimensions

Length: 24 ft 0 in 7.32 m7.32 m 24 ft 0 in
Wingspan: 31 ft 0 in 9.45 m9.45 m 31 ft 0 in
Wing area: 148 sq ft 13.8 m²13.8 m² 148 sq ft

Weights

Empty weight: 1,630 lb 739 kg739 kg 1,630 lb
Max take-off weight: 2,700 lb 1,225 kg1,225 kg 2,700 lb

Performance

Cruise speed: 171 kt 317 km/h317 km/h 171 kt
Max speed: 181 kt 335 km/h335 km/h 181 kt
Stall speed: 55 kt 101 km/h101 km/h 55 kt
Range: 717 nm 1,328 km1,328 km 717 nm
Service ceiling: 20,000 ft 6,096 m6,096 m 20,000 ft
Rate of climb: 1,450 ft/min 7.4 m/s7.4 m/s 1,450 ft/min

Powerplant

Engine: Lycoming O-540
Engine power: 260 hp 194 kW194 kW 260 hp

Capacity

Seats: 5

Manufacturer: Vans Aircraft
Country: United States
On the US register: 725
Registered in: Brazil, United Kingdom, New Zealand, Australia, United States, Canada

Improve this page

Add your photos Suggest a correction

RV-10 prices

25 for sale now

Year built Airframe hours Engine hours since overhaul

2015 · 390 h

USD

Low: $375,000
Typical: $404,000
High: $432,000

By year built · United States · USD
Built	Hours	Low	Typical	High
2005	720	$322,000	$346,000	$370,000
2010	540	$347,000	$374,000	$400,000
2015	390	$375,000	$404,000	$432,000
2020	180	$414,000	$446,000	$477,000
2025	120	$448,000	$482,000	$515,000

By year built · United Kingdom · GBP
Built	Hours	Low	Typical	High
2005	1,040	£202,000	£254,000	£317,000
2010	740	£219,000	£275,000	£343,000
2015	540	£236,000	£298,000	£371,000
2020	180	£265,000	£333,000	£415,000
2025	100	£288,000	£362,000	£451,000

By year built · Euro countries · EUR
Built	Hours	Low	Typical	High
2010	460	€238,000	€299,000	€373,000
2015	460	€253,000	€318,000	€397,000
2025	10	€321,000	€404,000	€503,000

By year built · Elsewhere · USD
Built	Hours	Low	Typical	High
2005	1,170	$332,000	$357,000	$400,000
2010	1,040	$356,000	$383,000	$428,000
2015	800	$383,000	$413,000	$461,000
2020	260	$431,000	$464,000	$519,000
2025	70	$483,000	$520,000	$581,000

RV-10 running costs

$384 an hour

Hours a year Aircraft value (USD)

A year
	Low	Typical	High
Fuel	$8,909	$11,480	$13,440
Oil	$208	$260	$338
Engine overhaul reserve	$3,333	$3,958	$5,192
Propeller overhaul reserve	$917	$1,083	$1,250
Annual inspection and maintenance	$3,000	$4,000	$5,000
Hangar	$3,000	$6,300	$9,600
Insurance	$3,891	$4,839	$5,787
Depreciation	$3,218	$6,435	$9,653

Total	$26,476	$38,355	$50,260
Per hour	$265	$384	$503
