1969 Piper Cherokee 6/300

General

Manufacturer

PIPER

Model

CHEROKEE 6/300

Condition

Used

Flight Rules

IFR

Airframe

Total time

5,070

Max Takeoff Weight

1,542.21 kg

Basic Empty Weight

857.74 kg

Useful Load

682.66 kg

Fuel Capacity Volume

317.97 L

Complete Logs

Yes

SB-1372 Calculated Service Hours are 2111.5 Eddy Current Due @ 4500 Calculated Svc hrs. Clean wings and fittings. Previous damage @ 1574 hrs. Noted in Logs.

Engine

Engine 1 Make/Model

LYCOMING IO-540-K1A5

Engine Serial Number

RL-1548-48A

Engine Horsepower

223.71 kW

Engine 1 Time

1,070 SFRM

Engine TBO

2000

Engine Manufacturer

Factory Lycoming Remanufactured. Not O/H. New exhaust installed @ engine installation.

Propeller

Prop Manufacturer

HARTZELL

Prop Model

HC-C2YK-1BF

Prop Time

1477.3 SOH

Number of Blades

2

Blade Composition

Aluminum

Avionics

GPS 1 Manufacturer

APOLLO

Transponder 1 Manufacturer

NARCO AVIONICS

Transponder 1 Model

AT150

Auto Pilot

Yes

ADS-B Equipped

Yes

Terra Audio Panel W/MB, Soft/Comm intercom, KX155, KX 196, Narco AT-150 TSO TXP. Shadin Mini-flo

fuel computer.

Equipment

3-Point Front Restraints. Good Grey-Tint Heavy windows/windshield, Tow-Bar, Cowling Plugs, Aircraft Cover, Sun-Foil Window Shades, Rosen Sun visors. Utility conversion. Aluminum Side Panels aft of Main Spar, 1/2 inch flooring, Sub-floor Storage, Multiple tiedowns.

Interior

Year Interior

2002

Number of Seats

3

Configuration

Passenger

Pilot/ Co-pilot Seats installed. Middle Jump seat can be put in. Remaining seats and interior side panels avail.

Exterior

Year Painted

2002

Maintenance

Inspection Status

Annual 4-2026

Airworthy

Yes
