How much does a used Grumman American Aviation AA-1B cost?

Name: Grumman American Aviation AA-1B
Brand: Grumman American Aviation

PLANEFILE

Grumman American AviationCertified · Fixed-wing · United States

AA-1B

Seats: 2 2
Power: 108 hp81 kW
Cruise: 109 kt201 km/h
US register: 26 aircraft26 aircraft

About the AA-1B

The American Aviation AA-1B is a fixed-wing, type-certificated aircraft built by American Aviation. It is a light, two-seat aircraft powered by a single flat-four engine, intended primarily for flight training and personal travel.

Development began as an unbuilt kit project before the creators pursued full regulatory approval for a factory-completed aircraft incorporating folding wings for storage convenience. Regulatory resistance to the folding wing configuration, costly certification procedures, and disputes between the principal designer and investors caused a major reorganization and a new name for the manufacturing firm.

Engines fitted

23 aircraft

Engine	Power	Share of fleet	Aircraft
Lycoming O-235	115 hp		23

This page covers the Grumman American Aviation GRUMMAN AA-1B: the same aircraft under other designations.

Specifications

AA-1A · Lycoming O-235-C2C

Dimensions

Length: 19 ft 3 in 5.87 m5.87 m 19 ft 3 in
Wingspan: 24 ft 6 in 7.46 m7.46 m 24 ft 6 in
Wing area: 98 sq ft 9.1 m²9.1 m² 98 sq ft

Weights

Empty weight: 1,016 lb 461 kg461 kg 1,016 lb
Max take-off weight: 1,499 lb 680 kg680 kg 1,499 lb

Performance

Cruise speed: 109 kt 201 km/h201 km/h 109 kt
Max speed: 120 kt 222 km/h222 km/h 120 kt
Never-exceed speed (Vne): 170 kt 314 km/h314 km/h 170 kt
Stall speed: 52 kt 97 km/h97 km/h 52 kt
Range: 424 nm 785 km785 km 424 nm
Service ceiling: 13,750 ft 4,191 m4,191 m 13,750 ft
Rate of climb: 770 ft/min 3.9 m/s3.9 m/s 770 ft/min

Powerplant

Engine: Lycoming O-235-C2C
Engine power: 108 hp 81 kW81 kW 108 hp

Capacity

Seats: 2

ICAO type designator: AA1
Manufacturer: Grumman American Aviation
Country: United States
On the US register: 26
Registered in: Australia, United States, Canada
Official website: gulfstream.com

Improve this page

Add your photos Suggest a correction

AA-1B prices

Asking prices of those for sale now, US dollars

Asking prices for the 2 Grumman American Aviation AA-1B aircraft for sale with a price run from $29,500 to $43,890, with a median of $36,700.

AA-1B running costs

$185 an hour

Hours a year Aircraft value (USD)

A year
	Low	Typical	High
Fuel	$3,926	$5,084	$5,914
Oil	$92	$115	$149
Engine overhaul reserve	$2,167	$2,667	$4,833
Annual inspection and maintenance	$2,500	$3,500	$4,500
Hangar	$3,000	$6,300	$9,600
Insurance	$630	$854	$1,077

Total	$12,315	$18,520	$26,073
Per hour	$123	$185	$261
