1990 Aviat Pitts S2-B

General

Manufacturer

AVIAT

Model

PITTS S2-B

Serial Number

5186

Registration #

N260MM

Condition

Used

Flight Rules

VFR

Airframe

Total time

1,600

Max Takeoff Weight

1,700 lb

Useful Load

463.34 lb

Complete Logs

Yes

SN

5186

Last Annual

May 2026

Last Pitot-Static/Transponder Insp

March 2025

May 2023

Repairs made to a section of the lower right leading edge due to bird strike.

July 1994

Log entry shows various fairings replaced, wings and tail re-rigged, lower wing anti skid replaced.

November 1994

Right horizontal stab replaced

Useful Load

463 lbs

• Complete and Original Maintenance Records
• Aircraft was completely recovered with new fabric and painted in April 2005
• All repairs are well documented in the maintenance logs.
• 6 gallon smoke system
• 25 gallon main tank usable fuel plus a 5 gallon aux tank
• Plexiglass floor in rear cockpit

Engine

Engine 1 Make/Model

LYCOMING AEIO-540-D4A5

Engine Serial Number

L-24329

Engine Horsepower

260 HP

Engine 1 Time

1,600 SNEW

Engine TBO

2000

Year Engine Overhauled or Installed as New

1990

Engine Time Remaining To Overhaul

400

SN

L-24329-48A

New Engine Mount Rubbers

February 2023

Both Magnetos Replaced

July 2025 at 1,440 Engine Hours

Latest Compressions

78, 70, 75, 79, 73, 75 /80

• Lycoming AEIO-540-D4A5 260 hp
• 1,600 SNEW (2,000 Hour TBO)
• Crankshaft replaced in July 1994

Propeller

Prop Manufacturer

MT

Prop Model

MTV-9-B-C

Prop Time

150 SMOH

Number of Blades

3

Blade Composition

Aluminum

Hub SN

94263

Blade SNs

LJ5503, LJ5504, LJ5505

Overhauled by Tiffin Aire

May 2023

• MT Propellor MTV-9-B-C/C190-18A 3 Blade
• 150 SPOH

Avionics

• Avionics Master Switch
• King KY197A Com Radio
• King KT76A Transponder
• GDL 82 ADS-B Out
• King KLN89B GPS (INOP)
• PS Engineering PM3000 Intercom
• Dual G Meters (1 in forward, 1 in aft cockpit)
• HOBBS Meter
• Christen Digital Fuel Flow/Used Gauge
• Throttle Mounted PTT Switch
• Panel Mounted Smoke On/Off Switch

Equipment

Modifications/Conversions

6 Gallon Smoke System

• Plexiglass Panel Mounted Clipboard
• Plexiglass Rear Cockpit Floor
• Cowel Flaps
• Ratcheting 5 Point Seat Restraints

Exterior

Year Painted

2005

Aerothane Eagle Red, Polar Gray, Insignia Blue

Registration

Registration

N260MM

Registered as

Christen Industries Inc PITTS S-2B

Year

1990

Serial number

5186

Engine

Lycoming Aeio-540 Ser · 260 hp

Certificate

Standard

Airworthiness date

1990-05-21

Registered since

2023-05-11

Registration valid to

2030-05-31

Status

Valid

Accidents and incidents

None on record
